> Products>Autoterm 2D-12 (Marine)
Planar 2d12V(Marine) View larger

Display all pictures

Air-heater 12V Autoterm 2D-12 (Marine)

SB.4390M



Parameter Code

Version

PLANAR–2D–12

PLANAR–2D–24

Nominal Supply Voltage, V

12

24



Fuel Type

Diesel Oil



Heating Efficiency:



1,8

max, kW,

min, kW,

0,8

Heated Air Volume:



75

Max , m3 /h

Min, m3 /h

34

Fuel Consumption at:



0.24 (0.06)

Max power, l/h (gal/h)

Min power, l/h (gal/h)

0.1 (0.03)

Heater power consumption, W



29



29

Doesn’t exceed while heating

mode

Max, W

Min, W

10

10

Start/Stop Mode

Manual

Maximum Weight, kg

3

More details

504,13 €

More info

The heating device is independent heating unit that consists of:

-heater 2kW;
-silent fuel pump;
-exhaust pipe Ø24mm (1 meter);
-isolation (1 meter);
-exhaust silencer;
-cable for pump;
-cabel for control panel (7 meter);
-cable for battery(6,5 meter);
-bracket is L-shaped;
-exhaust hull fitting 24mm.

This set is the perfect choice for heating of small boats.The heater is provided with waterproof joints, a stainless steel combustion chamber and an insulated control unit. For heating the air indoors, it is recommended to purchase the accessories and the air pipe diam.60mm.

Accessories
