> Products>Autoterm 9D-12
Planar 9kW-12v View larger

Display all pictures

Air-heater 12V Autoterm 9D-12

SB.3910

Parameter Code

Version

PLANAR 9D–24

PLANAR 9D12

Nominal Supply Voltage, V

24

12

Fuel Type

Diesel Oil



Heating Efficiency:

max, kW,

min, kW,



8

3,2



8

3,2

Heated Air Volume:

Max , m3 /h

Min, m3 /h



290

70



290

70

Fuel Consumption at:

Max power, l/h

Min power, l/h



1

0,42



4

0,42

Start/Stop Mode

Manual

Maximum Weight, kg

15

Heater power consumption, W

Doesn’t exceed while heating mode

Max, W

Min, W







215

12







215

12

More details

710,74 €

More info

The heating device is independent heating unit that consists of:

-heater 8kW;
-fuel pump;
-exhaust pipe Ø38mm (1 meter);
-cable for pump;
-cabel for control panel (1,8 meter)
-cable for battery(6,5 meter )
-fuel standpipe;
-T-fuel tube;
-tank 7l.

It is the most effective solution for heating of cargo spaces for transport of goods sensitive to low temperatures and heating of large-space cabins for transport of persons, and for heating of various spaces such as garages.

Accessories

Download

Manual Planar 9D

Download (1.78M)

Certifikat Planar 9d

Download (608.02k)
